Specifications
Identificaton
- Article number
- 42GS41MW
- GTIN
- 8718035002075
Technical specifications
- Collation type
- Plastic collated
- Wire material
- Carbon steel standard tensile
- Rotations per minute
- 2300, 2500, 3000, 3300 RPM
Fastener specifications
- Finish
- Weatherex II
- Application environment
- Outdoor
- Point type
- Self drilling wings
- Pointangle
- 110 °
- Screw head type
- Flat with 8 nibs
- Screw recess
- Square 2
- Screw thread type
- Fine
- Amount fasteners on strip/coil
- 50 - 50
- Screw length
- 41.0 mm
- Screw diameter
- 4.2 mm
CE Specifications
- DOP No
- 42GS41MW
- Material notification on CE label
- Non-alloy steel
- Service class
- 3
- Inner threaded diameter
- 3.5 mm
- Threaded/profiled length
- 29.3 mm
- Harmonized standard
- EN 14566:2008+A1:2009
Non-technical specifications
- Package quantity
- 1000
Logistical specifications
- Net weight
- 3.5 kg
