Flooring/decking wood to wood screw 4,2x55mm

Specifications

Identificaton

Article number

42W55MWN

GTIN

8715274251844

Technical specifications

Collation type

Plastic collated

Wire material

Carbon steel standard tensile

Rotations per minute

2300, 2500, 3000, 3300 RPM

Fastener specifications

Finish

Weatherex II

Application environment

Outdoor

Point type

Type 17 cut point

Pointangle

23 °

Screw recess

Senco drive 25

Screw thread type

2/3 coarse

Amount fasteners on strip/coil

50 - 50

Screw length

55.0 mm

Screw diameter

4.2 mm

CE Specifications

DOP No

42W55MWN

Material notification on CE label

Non-alloy steel

Service class

3

Inner threaded diameter

3.15 mm

Threaded/profiled length

36.6 mm

Characteristic yield moment

3283.0 Nmm

Characteristic head pull through parameter

16.0 N/mm²

Characteristic tensile strength

5112.0 N/mm²

Torsional ratio

≥ 1,5

Characteristic torsional resistance

1.74 Nm

Characteristic torsional strength

3.47 Nm

Harmonized standard

EN 14592:2008+A1:2012

Characteristic withdrawal parameter

12.0 N/mm²

Non-technical specifications

Package quantity

4000
