PAL57F, pallet coilnailer, double handed safety

Article number PAL57F-2H

tap image to zoom

Description

The Pal57F coilnailer is designed to drive up to a 57mm nail. Built for high speed operations and designed to handle the toughest production applications. For boxes, crates, carton-to-skid and pallets applications. The double safety requires two hands to fire a nail. First press the handle on the front side of the machine with one hand and pull the trigger with the other hand. This will prevent user from firing the tool using only one hand. This will lead to additional safety in the working environment.

Features & Benefits

  • Aluminium housing
  • Side steel wearplates
  • Comfort grip

Applications

Pallets and crates, Packaging, Subfloor, Framing, Sheathing

Find dealer Find dealer Request information Request information

Specifications

Identificaton

Serie
PalletPro
Article number
PAL57F-2H
GTIN
8715274183053
Type
PAL57F

Technical specifications

Collation angle
16 °
Wounding type
Flat
Oil free
No
Operating temperature
-18 - 49 °C
Collation type
Wire collated
Firing mode
Dual
Magazine capacity
300
Shots / second
3
Air inlet size
3/8" female
Air consumption at 60 shots/minute
87.0 l/m
Operating pressure
4.8 - 8.3 bar
Sound pressure level
87.2 Lpa
Sound power level
96.5 Lwa
Vibration level
3.03 m/s2

Fastener specifications

Type of nail
Coilnails
Smooth shank type
Smooth shank
Smooth shank nail length
25 - 57 mm
Smooth shank nail diameter
2,1 - 2,5 mm
Ring shank type
Ring shank
Ring shank nail length
25 - 57 mm
Ring shank nail diameter
2,1 - 2,1 mm
Pitch min
6.8 mm
Pitch max
6.8 mm
Max outerdiamer coil
121 mm

Non-technical specifications

Warranty
1 year
Dimensions (DxWxH)
133 x 302 x 286 mm
Includes case
No

Logistical specifications

Net weight
2.67 kg
